Key Features

1. High-Speed Precision Control
   • 24-bit encoder enables ±0.01mm repeatability, critical for semiconductor manufacturing, LCD panel handling, and precision assembly.
   • MECHATROLINK-III protocol supports 125μs communication cycles, ensuring real-time trajectory accuracy.
2. Robust Design for Industrial Environments
   • IP65-rated housing protects against dust, oil mist, and coolant splash, suitable for harsh factory conditions.
   • Reinforced shaft and bearing structure (20,000-hour bearing life under rated load) enhance durability.
3. Flexible Configuration Options
   • Brake System: Optional DC24V electromagnetic brake (150%+ rated torque holding).
   • Feedback: Selectable 17-bit or 20-bit encoders for tailored precision.
   • Connectors: Straight cable exit or aviation plug options for easy integration.
4. Dynamic Performance
   • High-density windings achieve a torque constant of 0.32 Nm/A, with a response frequency up to 1.2 kHz.
   • 350% instantaneous torque capability (for high-inertia loads) and 6000 RPM max speed.
5. Thermal Management
   • Optimized heat dissipation allows continuous operation at 40°C ambient temperature without derating.
