SIEMENS 6ES7322-5HF00-0AB0 SIMATIC S7-300,Digital Output SM 322 :

SIMATIC S7-300, Digital output SM 322, isolated, 8 DO (relay), 1x 40-pole, 24 V DC, 120-230 V AC, 5 A with RC filter overvoltage protection

The 6ES7322-5HF00-0AB0 is a digital output module from Siemens' SIMATIC S7-300 series, part of the SM 322 family. Designed for high-reliability industrial automation, this module features 8 isolated relay outputs with fault protection, supporting both AC and DC loads. It integrates channel-to-channel and channel-to-backplane isolation, ensuring robust signal integrity and reducing electromagnetic interference. The module supports hot-swapping for seamless maintenance and includes diagnostic LEDs for fault indication. It is ideal for controlling actuators, valves, and motors in harsh environments.

Technical Specifications:

Product Series: SIMATIC S7-300 SM 322 Digital Output Module

Output Channels: 8 relay outputs (fault-protected)

Output Type: Isolated relays (AC/DC compatible)

Voltage/Current: 24 V DC, 2 A per channel (max. 4 A per group)

Isolation: Channel-to-channel and channel-to-backplane isolation

Power Supply: 24 V DC (backplane-powered)

Diagnostic Features: Red LED fault indication, diagnostic interrupts

Configuration: STEP 7 software for parameterization (output type, data format)

Connection: 20-pin front connector, shielded cables (max. 320 m @ 125 kHz)

Environmental: -20°C to 60°C operating temperature, RoHS compliant

Physical Dimensions: 40 mm (W) × 125 mm (H) × 120 mm (D), 235 g weight

Protection: IP20 rating, overcurrent and short-circuit protection

Compliance: CE, UL, and RoHS standards

Application Areas: Industrial automation, actuator control, and discrete manufacturing processes requiring fault-tolerant outputs.

Packing & Delivery:

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.
